Dissection Tool Kit
手术剪1 x Geuder Dissection Scissor (1把手术剪刀)
3 x Dumont Forceps (3个镊子)
2 x Petri Dishes (2个碟子)
Part No. DTK-4000
Geuder Dissection Scissor(Geuder 手术剪刀)Trabeculum straight scissor - 8cm long.
Part No. DS-1000
Dumont Forcep (镊子)
Dumostar #5, 11cm long and 1.0x0.06mm tips high quality and matt finish.Part No. DF-3000
Petri Dish
90mm Glass Petri Dish coated with 5mm Sylgard. Used for fixation of the tissue during dissection.Part No. PD-2000
Stainless Steel Mounting Jaws 不锈钢固定钳
Usable with myograph models: 310A, 410A, 510A & 610M.Part No. SSJ-345610 (set of 2 jaws)
Mounting Screws & Screwdriver 固定钳及备用螺丝
For the stainless steel mounting jawsPart No. SS-345610 (12 screws & 1 screwdriver)
Plastic Mounting Jaws For Field Stimulation 电刺激用塑料固定钳
Used for performing experiments with field stimulation.Usable with myograph model 310A, 410A, 510A and 610M.
Part No. PJ-345610 (set of 2 jaws)
Part No. PJC-345610 (set of 2 jaws & connecting cable - phone jacks / BNC)
Mounting Pins 固定针
Used for ring preparations with lumen >500μm. Usable for myograph model 610M and 700MOPart No. MO-200 (200μm pins)
Part No. MO-250 (250μm pins)
Part No. MO-300 (350μm pins)
Part No. MO-400 (400μm pins)
Mounting Jaws – Reverse 固定钳
Accomendates low working distance. Usable on myograph model 120CWPart No. RJ-120 (set of 2 jaws)
Stainless Steel Wire 不锈钢金属线
40μm wire for mounting of ring preparations with lumen >100μm.Part No. SSW-123456 (appr. 1.500m per role)
Tungsten Wire 乌丝
25μm wire for mounting of ring preparations with lumen >60μm.Part No. TW-345610 (appr. 25m per role)
Chamber Cover - 310A 310A槽盖板
Chamber cover with ports for draining, filling & oxygenation.Part No. CC-310
Chamber Cover - 410A & 510A 410A&510A槽盖板
Chamber cover with ports for draining, filling & oxygenation.Part No. CC-4510
Chamber Cover - 610M & 700MO 610M&600MO槽盖板
Chamber cover with ports for draining, filling & oxygenation.Part No. CC-61700
Chamber Cover for Field Stimulation 电刺激用槽盖板
Used for performing experiments with field stimulation using mounting pins.Usable with myograph model 610M and 700MO.
Part No. CCE-61700
High Vacuum Grease 高真空润滑油
For sealing the transducer pin-hole in the myograph chambers - avoid fluid from entering the transducer housing.Part No. HVG-1000 (50g)
Plastic Funnels 塑料漏斗
Fits the holes in the myograph chamber coversPart No. F-2000
Force Calibration Kit 张力校准包
Used for calibrating the force transducer. Consist of 2g weight, bridge and T-balance.Usable for myograpgh models 310A, 410A and 510A
Part No. CK-345110
Force Calibration Kit 张力校准包
Used for calibrating the force transducer. Consist of 2g weight, bridge and T-balance.Usable for myograpgh models 610M and 120CW
Part No. CK-6127800
Force Transducer 张力换能器
For Myograph models 310A, 410A & 510ARange: +/- 200mN
Resolution: 0.01mN
Part No. FT-34510
Force Transducer 张力换能器
For Myograph model 610MRange: +/- 200mN / 400mN / 800mN & 1600mN
Resolution: 0.01mN
Part No. FT-61780
Force Transducer张力换能器
For Myograph model 120CWRange: +/- 200mN
Resolution: 0.01mN
Part No. FT-12110
BNC Cable BNC线
3m BNC/BNCPart No. BNC-345678
Electronic Valve 电子阀
Electronic valve used for rapid suction/draining of the chamber.Usable for myograph models 310A, 410A and 510A
Part No. EV-34510
pH Meter PH计
Enables the built-in pH meter in the myograph interface.Part No. PMP-34511
Combined Stimulator - CS200 组合刺激器
4-channel combined pulse and train generator.Part No. CS-200 (4-channel)
PowerLab Data Acqisition System
A 4-channel data acquisition system suitable for use with all wire myographs.Part No. PL-ML845
PowerLab Data Acqisition System PowerLab数据分析系统
A powerfull 4-channel data acquisition system suitable for use with all wire myographs.Part No. PL-ML866
Avaliable in 8- and 16-channels systems
DMT Normalization Module (Win & Mac) - V 1.1 DMT标准化模块
Normalization add-on to Chart Acquisition software. Enables the normalization procedure to be done using Chart. Requires Chart v. 5.3 or later.Part No. MLS065
